Installation Diagrams - Single Orbital Location Wing Dish Options 3 - 3
Single Orbital Location Wing Dish Options
LNBFs Switch Receivers/Tuners Supported Diagram
110º, 118.7º, & 119º (3 Orbital Locations)
(if needed) (without additional switches)
DISH 500+
DP 500+ LNBF Assembly DP34 Switch 2 dual or 4 single-tuners n/a
DP 500+ LNBF Assembly DPP33 Switch 3 dual (w/ DPP Separators) or 3 single-tuners 12
110º, 118.7º, 119º, with Wing Dish (4 Orbital Locations)
DISH 500+ with Wing Dish* DP 500+ LNBF Assembly and DP Dual/Single DPP44 Switch 4 dual (w/ DPP Separators) or 4 single-tuners 13
110º, 118.7º, 119º, and 129º (4 Orbital Locations)
DISH 1000+ DP 500+ LNBF Assembly, 1000+ Bracket, & DP Dual/Single DPP44 Switch 4 dual (w/ DPP Separators) or 4 single-tuners 14
61.5º, 72.7º, and 77º (3 Orbital Locations)
1000.4 Assembly
DP Plus1000.4 LNBF n/a 3 dual (w/ DPP Separators) or 3 single-tuners 15
DP Plus 1000.4 LNBF DPP44 Switch 4 dual (w/ DPP Separators) or 4 single-tuners 16
61.5º, 72.7º, 77º and 118.7° (4 Orbital Locations)
1000.4 Assembly DP Plus 1000.4 LNBF, DP 500+ LNBF Assembly DPP44 Switch 4 dual (w/ DPP Separators) or 4 single-tuners n/a
* See Single Orbital Location Wing Dish Options. Wing dish must use a DP-compatible LNBF.
LNBFs Diagram
DBS: 61.5º, 72.7º, 77º, 110º, 119º, 129º, or 148º
DISH 500 w/ I-Bracket, or other approved dish** Dual: DP or Legacy—must match other LNBFs/switches in installation 17
FSS: 105º or 121º
105 or 121 SuperDISH FSS LNBF (DP-compatible only) n/a
** May include 24” dish or larger, depending on location.
