Ditch Witch 1330 - Power Train and Tires; Hydraulic System; Fluid Capacities; Noise and Vibration Levels

1330 Operator’s Manual Specifications - 77
CMW
Power Train U.S. Metric
Ground drive transmission: hydrostatic, two speeds infinitely variable from zero to maximum, gearbox to
axle, speed and direction controlled with single lever
Digging chain drive: hydraulic direct drive, lever-operated, one speed forward and reverse
Trencher drive: hydraulic direct drive
Pump drive: direct drive from engine
Spoils handling drive: mechanical, attached to and rotates with headshaft
Tires
Drive, standard: 16x6.50x8 15 psi 103 kPa
Drive, optional: 18x8.50x8 22 psi 152 kPa
Trail: 13x5.00x6
Hydraulic System U.S. Metric
Tandem pump capacity @ 3600 rpm
To digging drive 5.7 gpm 21.5 L/min
To ground drive 1.4 gpm 5.3 L/min
Total 7.1 gpm 26.8 L/min
Fluid Capacities U.S. Metric
Hydraulic reservoir 4.5 gal 17 L
Hydraulic system 5 gal 19 L
Worm drive oil 3.25 pt 1.5 L
Fuel tank 1.7 gal 6.5 L
Engine oil 2.3 pt 1.1 L
Noise Levels
Operator 86 dBA sound pressure per ISO 6394
Exterior 100 dBA sound power per ISO 6393
Vibration Levels
Vibration at the operator’s hand during normal operation is 8.4 m/s
2
