Controls - 36 420sx Operator’s Manual
Attachment Controls
CMW
Item Description Notes
1. Plow lift control To lower, push.
To raise, pull.
2. Boom lift control To lower, push.
To raise, pull.
3. Plow vibrator switch To start, set switch to the on
position.
To stop, set switch to the off
position.
IMPORTANT: Switch must be in the
off position in order to start engine.
4. Trench/Roto Witch
mode select switch
(optional)
To operate in Roto Witch
mode, set switch to the RW
position.
To start trencher in forward,
set switch in the trench
position.
To disengage front
attachments, put switch in
center position.
IMPORTANT:
• Switch must be in the center
position in order to start engine.
• Digging chain will start turning
when switch is moved to the
trench position.
• When drilling, use the drill
direction switch (page 37) to start
forward or reverse rotation of
Roto Witch.
