Controls - 28 RT80 Operator’s Manual
Center Console
CMW
Controls
1. Reel carrier control*
2. Horn
3. Drilling attachment control*
4. Ignition switch
5. Ground drive foot control
6. Hydraulic ground drive motor speed control
7. Transmission gearbox speed control
8. Auxiliary outlet
*optional
Item Description Notes
1. Reel carrier control To raise, press top.
To lower, press bottom.
c00ic205h.eps
