CHAPTER 5

PROTOCOL AND OPERATIONAL WORK

5-3

Displays for series DT-203NN, DT-105NN and DT-110NN

5.1.2 Download GSD file.

On our website, on the download page you can find the file GDSML_DTNN_V2.31.zip,

with all the configuration files for the DT-NN family.

Once unzipped, there will be a set of .xml files. You should consult the display item

code (label located in the connectors’ area) to select the right file. From this label; the model

information, number of lines and characters can be obtained.

Our item codes have the following format:

• Single-sided models:

• Double-sided models:

For example, our item code DT-105/1S-6, corresponds to the model DT-105 with 1 line

and 6 characters. The same GSD is used for single-sided (S) or double-sided (D) models.

You will select your GSD file according to model, number of lines and number of characters.

GSDML-V2.25-XXXxxx-XXXXXXX-<Model>_<number of lines>L_<number of characters>C-XXXXXXXX.xml

For the previous item code example, the GSD to use would be:

GSDML-V2.25-XXXxxx-XXXXXXX-DT105_1L_6C-XXXXXXXX.xml

5.1.3 Creating a GSD custom file.

In the case that you need avoid the duplicity of devices with the same Device Name,

you must use the SW67602 software to change the Profinet parameters, create the new GSD

and update the Display Firmware.

Find and download the GSD file FW_Lartet_DT-NN.zip at our website, containing the

configuration project for the DT-NN display family.

Once unzipped, you will get a set of folders, with the model name, number of lines and

number of characters.

As described in the previous section, from the item code you can get the model, number

of lines and characters of the display.

For example, to work with a DT-105/1S-6 the folder DT105_1L_6C must be selected

which contains the configuration files.

Once installed the software SW67602, you will find the folder “Projects” in the

installation directory of this program. The folder that we have selected with the configuration

files, must be moved inside “Projects” folder.
