dixell XR20C User Manual

Controller ：DIXELL-XR20C
Parameter setting code：D20-001M
Parameter setting sheet for Entree Refrigerator
CODE
PARAMETER
SET
Set
Main Set point
34
Hy
Differential(hysteresis)
4
LS
Lower limit of main set point
28
US
Upper limit of main set point
50
Ot
Offset
-1
P2P
Evaporator probe presence
Y
OE
Evaporator probe calibration
0
Ods
Outputs delay at start up
0
AC
Minimum time interval between the disactivation and successive activation
on compressor
5
CCt
Continuous cycle duration
0
Con
Compressor on-time during by probe failure
10
COF
Compressor off-time during by probe failure
10
CF
Unit of measure
℉
rES
Resolution
dE
Lod
Probe displayed
P1
Edf
Defrost termination setting
Pb
dtE
Defrost-end temperature
41
IdF
Time interval between defrost cycle
6
MdF
Max defrost cycle time
20
dFd
Displaying during defrost
SEt
dAF
Defrost delay after fast freezing
0
dAd
Real temperature display delay at defrost end
30
ALC
Temperature alarms configuration
rE
ALU
Max temperature alarm differential
50
ALL
Minimum temperature alarm differential
20
ALd
Minimum or minimum temperature alarm delay
60
dAO
Delay of temperature alarm at start up
1
i1P
Digital input polarity
CL
i1F
Digital input configuration
dor
did
Digital input alarm delay
15
NPS
Number of activation of pressure switch
15
Odc
Compressor and fan status when open door
no
Pbc
Kind of probe
ntc
dP1
Room probe display
--
dP2
Evaporator probe display
--
rEL
Software release
--
Ptb
Map code
--

dixell XR20C Specifications

General

Front Protection	IP65
Dimensions	74 x 32 x 60 mm
Resolution	0.1 °C
Power Consumption	3 VA max
Power Supply	230V AC ±10%, 50/60Hz
Operating Temperature	0 to 60 °C
Storage Temperature	-30 to +80 °C
Inputs	NTC or PTC
Measuring Range	NTC -50 to +110°C; PTC -55 to +150°C
Accuracy	±0.5 °C
Relative Humidity	20 to 90% RH (non-condensing)
Display	3 digits
Communication	Optional RS485 (Modbus RTU)
Protection Degree	IP65
