Before Leaving Checklist
• Before leaving the site, make sure to check the following items.
Appendix
Status Indicators
The status indicators on the dock cover are used to display the current operational status of the dock.
Normal States
Blinks white The dock is working normally and the aircraft is ready to take off.
Blinks blue The dock and the aircraft are linking, and the buzzer emits a short beep.
Blinks green The aircraft has taken off from the dock and is performing a flight task.
Solid blue The dock is updating or debugging (including remote debugging and on-site
debugging).
Warning States
Blinks red The dock covers are moving or the aircraft is taking off or landing, and the
buzzer emits a long beep.
Blinks red and yellow
alternately
The emergency stop button on the dock is pressed.
The HMS of DJI FlightHub 2 has no abnormal alarm.
The wind speed gauge module is mounted securely.
Check the wind speed gauge data displayed in DJI FlightHub 2 by rotating the wind speed gauge.
The rainfall gauge surface is clear of dirt and foreign matter.
The surge protector circuit breaker, AC power switch, and backup battery switch in the electrical cabinet
are turned on.
The landing pad surface is clear of dirt and foreign matter.
The protective sticker has been removed from the temperature and humidity sensor.
The aircraft is placed properly on the landing pad.
The port covers are correctly in place and securely sealed.
The lenses of the vision systems, gimbal cameras, glass of the infrared sensors, and auxiliary lights are
clean.
The dock covers are closed.
The dock cover surface is clear of dirt and foreign matter.
The electrical cabinet door is closed and locked.
The aircraft alternate landing site test has been completed.
Check whether the GEO Zone Unlocking License (if any) has been imported to DJI Pilot 2.
