2016 DJI. All Rights Reserved.
71
User Manual
INSPIRE RAW
Auto-Landing
Use auto-landing to land your aircraft automatically if the Aircraft Status Indicator displays blinking green.
Follow the steps below to use auto-landing:
1. Ensure the aircraft is in “P” mode.
2. Check the landing area condition before tapping “ ”, to perform landing.
3. Aircraft lowers the landing gear and proceed to land automatically.
Landing gear will automatically raise when the aircraft reaches an altitude of 1.5 m for the rst
time, and automatically lower every time it descends to 0.8 m. Users can turn this feature ON/
OFF in the DJI GO app.
Starting/Stopping the Motors
Starting Motors
The Combination Stick Command (CSC) listed below are used to start the motors instead of simply push-
ing the stick up. Ensure that you perform the CSC in one motion.
Flight Test
Take off/Landing Procedures
1. Place the aircraft on open, at ground with battery indicators facing towards you.
2. Power on the remote controller and your mobile device, then the Intelligent Flight Battery.
3. Launch the DJI GO App and enter the Camera page.
4. Wait until the Aircraft Indicator blinks green. This means the Home Point is recorded and it is safe to y
now. If it ashes yellow, it means Home Point is not recorded, and you should not take off.
5. Push the throttle up slowly to take off or using Auto Take-off to take off.
Stopping Motors
There are two methods to stop the motors.
Method 1: When the Inspire 1 RAW has landed, push the throttle down , then conduct CSC . Motors
will stop immediately. Release both sticks once motors stop.
Method 2: When the aircraft has landed, push the throttle down and hold. The motors will stop after 3
seconds.
Do not perform CSC when aircraft is in midair, otherwise the motors will be stopped.
OR
OR
