* Visit the Official DJI website and download the Inspire 2 User Manual for more
information on how to pair batteries using the DJI GO 4 app.
Overview
[3]
[1]
[2]
[8]
[6]
[5]
[4]
[7]
[1] Power Port
[2] Charging Port
[3] Charging Port Cover
[4] Battery Charging Level Indicators
[5] Cover/Battery Release Button
[6] Status LEDs
[7] Firmware Update Port ἷMicro USBἸ
[8] Buzzer Switch
Using the Charging Hub
Follow the instructions below to use the Charging Hub.
1. Connecting to a Power Source
Connect the standard Inspire 2 Battery Charger to a power outlet (100-240V,
50/60Hz), then uncover the rubber cover on the power port to connect the Charging
Hub to the Inspire 2 Battery Charger.
Power OutletChargerCharging Hub
