DJI OM 5

User Manual

5. The built-in extension rod can be extended to up to 215 mm and the angle can be

adjusted from 0 to 90 °.

Make sure the direction of the magnetic

phone clamp is the same as shown

and it is in the middle of the phone.

Otherwise, the gimbal performance may

be affected.

Adjust the phone clamp and make sure

it is as vertical like the phone.

For optimal performance, use the

provided riser pad if using a phone less

than 7.5 mm thick or weighing less than

170 g.

Mount the mobile phone before

powering on DJI OM 5. If no mobile

phone is detected, DJI OM 5 will vibrate

and enter standby mode. To bring it out

of standby mode, press any button after

mounting the mobile phone.

Questions and Answers:

Need help?

Do you have a question about the dji OM 5 and is the answer not in the manual?

dji OM 5 Specifications

General

Bluetooth	Yes
Bluetooth version	5.0
Type	Smartphone camera stabilizer
Material	-
Mounting	1/4\
Product color	Gray
Maximum device depth	10 mm
Maximum device width	84 mm
Minimum device depth	6.9 mm
Minimum device width	67 mm
Charging time	1.5 h
Operating time	6.4 h
Battery voltage	8.8 V
Battery capacity	1000 mAh
Operating temperature (T-T)	0 - 40 °C
Mechanical pan range	-161.12 - 172.08 °
Mechanical roll range	-127.05 - 208.95 °
Mechanical tilt range	-101.46 - 229.54 °
