dji OSMO MOBILE 2 User Manual

10
©
2018 DJI All Rights Reserved.
Connect the USB port to your mobile phone using a standard Micro USB cable. If the
Osmo Mobile 2 is powered on charging will start. If the Osmo Mobile 2 is powered off
press the Power/Mode button once to start charging.
The Osmo Mobile 2 cannot charge mobile phones while being charged itself. Do
not connect the USB port to a mobile phone while charging the Osmo Mobile 2.
4. Joystick
Move vertically to tilt the mobile phone. Move horizontally to
pan the mobile phone. Joystick control direction can be set in
the DJI GO app.
5. Shutter/Record Button
Press the Shutter/Record button once to start or stop
recording, or to take a photo. (To switch between photo and
video modes tap the Photo/Video switch in the DJI GO app).
Press and hold the Shutter/Record button for burst capture
(available on iOS only).
7. Charging Port (Micro USB)
Charge the Osmo Mobile 2 by connecting a USB adapter to
this port. Refer to the Charging section for more information.
6. Zoom Slider
Push up/down to zoom in/out.
8. USB Port
The USB port can be used to charge mobile
phones.

dji OSMO MOBILE 2 Specifications

General

Dimensions	295 × 113 × 72 mm
Weight	485 g
Battery Life	up to 15 hours
Compatible Phones Width	58.6 - 84.8 mm
Battery Capacity	2600 mAh
Gimbal Range Pan	±160°
Gimbal Range Roll	±170°
Max Controllable Speed	120°/s
Max Payload	202 g
Type	Handheld Gimbal
Bluetooth	Bluetooth 4.0
Compatibility	iOS and Android smartphones
Operating Temperature	0° to 40° C
Charging Time	2 hours
Storage Temperature	-20° to 45°C
