2016 DJI All Rights Reserved.
11
OSMO+ User Manual
RecordButton
ShutterButton
[2] Joystick
Vertical movement tilts the camera. Horizontal movement pans the camera. Joystick
Control Direction can be changed in the DJI GO app.
[3] Shutter Button
Press this button to take photos based on your settings in the DJI GO app. Hold down
shutter button to capture continuous photo.
[4] Record Button
Press this button once to start recording video, and again to stop recording.
[5] Camera Status Indicator
Indicates the camera’s system status. Refer to the table below for details.
Blinking Pattern Description
LED Off Camera is functioning normally.
Blinks Green Shooting photo.
Blinks Green slowly Self-timer.
Blinks Green for each shot Burst shooting.
Solid Green Firmware upgrade successful.
Blinks Red slowly
Recording video.
/ Blinks Red and Green alternately Upgrading rmware.
Solid Red
Camera is not mounted on the Osmo+ properly /
Firmware upgrade failed or system error.
×2 Blinks Red twice Camera error.
Blinks Yellow Micro SD card busy.
Solid Yellow Micro SD card error.
CameraStatusIndicator
Joystick
