Maintenance
When transporting the Osmo+, keep it locked, in order to protect the gimbal, as shown below.
The Osmo+ is not water resistant. Keep it away from sand and dust during use. After use, it
is recommended to wipe the Osmo+ down with a soft dry cloth. Never spray any cleaning
liquids onto the Osmo+.
Specications
Handle
Dimensions 2.4×1.9×6.4 inches (61.8×48.2×161.5 mm)
Weight (including battery) 201 g
Gimbal
Model Zenmuse X3 Zoom
Weight 268 g
Output Power (with camera) 8 W
Angular Vibration Range ±0.02°
Mount Detachable
Controllable Range
Tilt: -35° to +135°
Pan: ±320°; Roll: ±30°
Mechanical Range
Tilt: -50° to +140°
Pan: ±330°; Roll: -50° to +90°
Max Controllable Speed 120°/s

dji OSMO+ Specifications

General

Video resolutions	1920 x 1080, 2704 x 1520, 3840 x 2160, 4096 x 2160 pixels
Maximum frame rate	60 fps
Supported video modes	1080p, 2160p
Video formats supported	AVC, H.264, MOV, MP4, MPEG4
Maximum video resolution	4096 x 2160 pixels
Wi-Fi	Yes
Frequency band	2.4/5 GHz
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	64 GB
Operating temperature (T-T)	0 - 40 °C
Megapixel	12.4 MP
Image formats supported	DNG, JPG, RAW
Maximum image resolution	4000 x 3000 pixels
Maximum aperture number	5.2
Minimum aperture number	2.8
Product color	Black

Weight and Dimensions

Depth	48.2 mm
Width	61.8 mm
Height	161.5 mm
Weight	201 g
