dji OSMO+ User Manual

©
2016 DJI All Rights Reserved.
9
OSMO+ User Manual
Visit the ofcial DJI Store (http://store.dji.com) to learn more.
Vehicle Mount
Triple suction cup mount makes it ideal for mounting on
top of or on the rear window of moving vehicles.
Straight Extension Arm
Used to attach up to three other mounts at the same time.
Unlocking the Gimbal
To protect the gimbal, the motor axes are locked in place. To unlock the gimbal:
1. Gently rotate the roll motor until it can rotate freely.
Rotate the motor just enough to allow free motion.
2. Slide the Pan Axis Lock upwards to unlock the pan axis.
Pan Axis Lock
2

dji OSMO+ Specifications

General

Video resolutions	1920 x 1080, 2704 x 1520, 3840 x 2160, 4096 x 2160 pixels
Maximum frame rate	60 fps
Supported video modes	1080p, 2160p
Video formats supported	AVC, H.264, MOV, MP4, MPEG4
Maximum video resolution	4096 x 2160 pixels
Wi-Fi	Yes
Frequency band	2.4/5 GHz
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	64 GB
Operating temperature (T-T)	0 - 40 °C
Megapixel	12.4 MP
Image formats supported	DNG, JPG, RAW
Maximum image resolution	4000 x 3000 pixels
Maximum aperture number	5.2
Minimum aperture number	2.8
Product color	Black

Weight and Dimensions

Depth	48.2 mm
Width	61.8 mm
Height	161.5 mm
Weight	201 g
