Horizontal Shooting
1. Loosen the lever
①
on the lower quick-release plate.
2. Insert the upper quick-release plate with the camera attached into the lower quick-release
plate
②
, as shown below.
3. Adjust the lower quick-release plate to an appropriate position according to the width of the
camera, and then tighten the lever
③
.
2
3
1
2
3
1
•
The position of the lower quick-release plate on the horizontal arm can be adjusted
according to the width of the camera. Loosen the red lever on the lower quick-release
plate and then move the lower quick-release plate.
•
To remove the upper quick-release plate, loosen the gray lever on the lower quick-
release plate and press and hold the safety lock beside the lever.
