dji WIND-4

38
Diagonal Wheelbase
1060 mm
Propulsion System
Model
E5000 Pro
Motors
Stator Size
100x10 mm
KV
120 rpm/V
Max. Thrust
14 kg/rotor when the elevation is 0 m above sea level
ESCs
Max. Allowable Current
80 A
Max. Operating Voltage
52.2 V
Compatible Signal Frequency
30-500 Hz
PWM Input Signal Level
3.3 V/5 V
Foldable Propellers
Material
High-strength plastic
Size
28

7 inch
ESC
520 g
Flight Parameters
Total Weight (With a DZ-12000 Battery)
11.7 kg
Max. Takeoff Weight
21 kg (10.5 min)
Battery
DZ-12000 battery
Hovering Time
22.07 min (DZ-12000 battery + Zenmuse Z3)
Max. Flying Speed
18 m/s
Max. Service Ceiling Above Sea Level
3000 m
Operating Temperature Range
-10°C to +40°C
Remote Controller
Model
GL658C
Operating Frequency
2.400 GHz to 2.483 GHz
Max. Transmission Range (Unobstructed and
Free of Interference)
3 km (FCC)
2.5 km (CE)
Power Supply
Built-in lithium battery
Charging
DJI charger
Output Power
9 W
Operating Temperature Range
-10°C to +40°C
Storage Temperature Range
Less than 3 months: -20°C to +45°C
More than 3 months: 22°C to +28°C
Charge Temperature Range
0°C to 40°C
Battery
6000 mAh, 2S LiPo
Charger Input Characteristics
Model
C03048D
