Zenmuse H20
Series
User Manual
10
©
2020 DJI All Rights Reserved.
ROI set to “Full” Sky excluded from ROI
Scene Parameter*
• DDE (Digital Detail Enhancement): Enhances image details and/or suppresses fixed pattern
noise.
• Contrast: The ratio of the black and white of the image. Colors will be richer and have more
contrast when the value is high.
• Brightness: The brightness of the image.
Gain Mode*
High Gain Mode: A narrower temperature range can be captured with a higher sensitivity to
temperature differences.
Low Gain Mode: A wider temperature range can be captured with a lower sensitivity to temperature
difference.
Temperature Alert*
After enabling the Area measurement feature, an alert temperature value can be set.
When the highest temperature in the selected area exceeds the alert value, an onscreen notication
will appear in DJI Pilot.
Auto FFC*
Enable or disable the automatic FFC calibration. The infrared thermal camera will automatically
calibrate at regular intervals.
Gridlines
Enable or disable the gridlines or diagonal.
Smart LED
Enable or disable smart LED such as frame arm LEDs or beacon.
Reset Camera Settings
Tap to reset the camera to the default settings.
Format SD card
Tap to format and remove all content from the microSD card. Operate with caution.
7. Photo/Video Toggle
Tap to switch between photo and video modes.
8. Zoom Slider (Zoom camera)
Tap to adjust the zoom magnication level of the zoom camera.
If the main screen shows the zoom camera view, the liveview will be changed directly by adjusting
the zoom. Otherwise, only the zoom camera preview box in the middle of the screen will be
changed.
