18 Specifications
Alert Beeper 73dBa at 12". Programmable.
Applications Commercial, industrial, and residential remote power control and reboot. Indoor use
only.
Circuit Breakers Manual reset, 15A Thermal, UL
Clock / RTC 10 year Li battery
Controls / Display Reset-to-factory-default switch, 2x16 Backlit LCD w/ PowerSave, 5 button keypad
Dimensions 6.00 x 4.25 x 2.25" DIN compliant
Enclosure Injection molded high-temp thermoplastic, vented 5 sides
Ethernet Interface 10/100 autosensing, Static IP, TCP port selectable, 8 pin RJ-45 w/ internal FCC filter-
ing
FCC Testing Part 15 FCC ID 2ACOE-SKW71
Input Voltage 12-28VDC, UVLO approx 10.5V, safety Shutdown at 34VDC
Max Switched Power 8 x 10A at 125VAC Fused at 12A
Input Frequency Power supply - DC-400Hz
Operating Temperature -30° to 170°F, -34° to 77°C; designed for dry environments
Options - User Right-Angle 19" rack-mount bracket.
Power Supply Rating 90-240V, AC/DC Autosensing
Password Transmission Encrypted, base 64 or HTTPS
Power Dissipation 5.8W Typ Max (all on) <2 W idle
Power Fail Hold-Over 150ms minimum (24V, all relays on)
Power-Up Modes Last used settings, all power on or off, sequential on or run user-script ∼30s after
power-up
Relay Contact Spec T-90, 277V, 30/40A AC/DC, 1/2HP
Relay Debounce ∼200ms protection timer
Software Controls Individual outlets on/off , all on/off /cycle. Net settings, Web UI
UVLO Starts @ 11.5VDC, Shutdown 10.5V
Vibration Not intended for mobile or airborne applications. Contact factory for ruggedized vari-
ant.
Weight Bare unit 2.7 lbs, Ship wt. 3.6 lbs
WiFi Atheros 9331 2.4G 802.11n RP-SMA
FCC Note:
The DIN4 may only be used with
• the manufacturer supplied antenna (Gain: 2.0dBi),or
• a 50 Ohm antenna of equal or lesser gain.
DLI DIN4 User’s Guide: 20170809T111540Z
