DMN-WESTINGHOUSE AL-BL Rotary Valves
Code: AL-E.B.01.B 11-2012
11
2.4.2 Mounting the valve in the system
When installing the valve make sure it is not unevenly loaded
by external forces or vibrations.
During operation or testing the inlet / outlet and vent hole
connections must not be open or unprotected
- If it is a blowing seal, the conveying pipe line to be connected to the blowing
seal should ideally have the same diameter as the connections on the seal.
- If there is some difference between the inner diameters of the blowing channel
and the conveying line, the transition from one diameter to the other should be
as smooth as possible.
- If the valve is fitted with air vents, the area of the venting pipe should be equal
to the total area of both vent connections.
Remove all packing material and preservatives.
Check for any transport damages.
Installation procedure
Please respect safety instructions.
- Install the valve stress free
- Connect conveying pipes stress free
- Connect air vent pipe work
- Connect air purge supply and adjust pressure regulator
- Fasten gland packing (see 3.1.3.2)
- Connect motor
- Check rotating direction (see fig. 2.4.1.1)
The rotary valves must not be put into service until the equipment
into which they have been incorporated have been declared in
conformity with the Machinery Directive.
