3.3 Operation instructions AL HT execution 600C
3.3.1 General
The type AL-HT rotary airlocks are designed for the metering of products in powder
form for temperature to 600 C.
The limits stated in the technical specification 3.3.2 should not be exceeded.
The user is responsible for any defects and/or risks or damages resulting from
improper use.
3.3.2 Technical specifications
AL-HT execution:
Operating pressure permitted : -0.5 to +2 Bar
No pressure difference over rotor
Temperature permitted : Cast iron GG 25/ Mild steel 250C to +400C
St.St 316/ St.St 316 250C to +600C
Materials:
housing & end covers
Cast iron GG25 Din 1691/0.6025
Stainless steel AISI 316 Din 17445/1.4408
Rotor
Steel St.37
Stainless steel AISI 316
Capacity: Rotor with 9 adjustable blades.
AL
150
175
200
250
300
350
AXL-AML
150
200
250
300
350
400
Ltr./Rev.
2,5
5,5
10,5
19
34
58
 Capacity per revolution at 100% filling
