DMN-WESTINGHOUSE AL-BL Rotary Valves
Code: AL-E.B.01.B 11-2012
47
3.7 Accessories
- Safety switch
Fig. 3.7.1 Safety switch.
510 Safety switch 541 Cylinder bolt
511 Fastening plate 542 Bolt
540 Countersunk screw 543 Nut
The safety switch must be connected to the client safety circuit,
which will stop or prevent the valve from operating.
Safety control module is not part of the DMN supply.
