3.1. Power and rotor speed rotary valves
The following tables show the power and rotor speed for each type and size of DMN-
WESTINGHOUSE valve.
For good functioning of the valve the rotor tip speed must not exceed 0.66m/sec.The
standard rotor speeds are usually between 15-25 RPM depending on size of valve.
The Power depends on the minimum required torque and rotor speed.
According to the ATEX directive the maximum velocity must not be
higher then 1 m/s and the maximum power of the motor gear unit is
not higher then 4 kW.
If higher velocity or power are required then please contact
DMN.
The ATEX approval ceases without prior consultation.
Type
Size
Minimum
torque
Max.
Power
Max. advised
Rotor speed
Max. allowed
Rotor speed
Rotor diameter
AL-BL
150
145 Nm
 0,75 kW
 30 RPM
 30 RPM
170mm
AL-BL
175
145 Nm
 0,75 kW
 30 RPM
 30 RPM
210mm
AL-BL
200
215 Nm
 1,1 kW
 30 RPM
 30 RPM
260mm
AL-BL
250
290 Nm
 1,5 kW
 30 RPM
 30 RPM
310mm
AL-BL
300
360 Nm
 1,5 kW
 30 RPM
 30 RPM
380mm
AL-BL
350
510 Nm
 1,5 kW
 28 RPM
 30 RPM
450mm
AL
400
1200 Nm
 3 kW
 23 RPM
 30 RPM
555mm
AL
450
1875 Nm
 4 kW
 20 RPM
 30 RPM
620mm
AL
500
2500 Nm
 4 kW
 18 RPM
 26 RPM
720mm
Type
Size
Minimum
torque
Max. Power
Max. allowed
Rotor speed
Rotor diameter
AML
150
145 Nm
 0,75 kW
 30 RPM
170mm
AML
200
145 Nm
 0,75 kW
 30 RPM
210mm
AML
250
215 Nm
 1,1 kW
 30 RPM
260mm
AML
300
290 Nm
 1,5 kW
 30 RPM
310mm
AML
350
360 Nm
 1,5 kW
 30 RPM
380mm
Type
Size
Minimum
torque
Max. Power
Max. allowed
Rotor speed
Rotor diameter
ML(D)
150
145 Nm
 0,75 kW
 30 RPM
170mm
