Digital Monitoring Products, Inc. | 734N Installation and Programming Guide 3
PCB FEATURES
DC INPUT
WIEGAND
INPUTS
ZONES
PIEZO
INDICATOR
LEDS
DOOR RELAY
NETWORK
CONNECTION
Figure 1: PCB Features
