Digital Monitoring Products, Inc | 7000 Series Installation and Programming Guide 14
Model 333
Supressor
Common
–+
Magnetic Door Lock
DMP 505
Power Supply
Normally Open
Green/White – D0
White – D1
Orange – N/O
Gray – C
Violet – N/C
N/O
C
N/C
Normally
Closed
Keypad
5-Wire Harness
Figure 7: 5-Wire Harness and 333 Suppressor Installation
