7000 Series Installation and Programming Guide | Digital Monitoring Products, Inc. 31
KEYPAD ARMING AND DISARMING
Area System Arming and Disarming
1. Press CMD until the keypad displays ARM DISARM.
2. Press the select key under the preferred option.
3. The keypad displays ENTER CODE: -. The user presents their card to the reader.
Once validated by the system, all areas assigned to that code arm or disarm automatically
and the 7073/A and 7173 keypad door strike relay activates. See Figure 9.
Figure 9: Area Arming and Disarming
ABC SECURITY
ARM DISARM
ABC SECURITY
ENTER CODE: –
ABC SECURITY
ALL? NO YES
Select NO to arm or disarm individual areas.
Select YES, or simply wait, to automatically arm or disarm all areas for which you are authorized.
