Digital Monitoring Products, Inc | 7000 Series Installation and Programming Guide 32
All/Perimeter System Arming and Disarming
Present the card to the reader or press CMD, the keypad displays DISARM? or PERIM ALL
(when arming). Press the select key under the desired option. The keypad displays
ENTER CODE: -. Present the card to the reader. Once validated by the system, the
selected areas arm or disarm automatically. On 7073/A and 7173 keypads, the Door Strike
relay then activates.
Home/Away System Arming and Disarming
Present your card to the reader. If the system is armed, once the card is validated, all areas
are disarmed and the keypad displays ALL SYSTEM OFF. If the system is disarmed when
you present your card, once the card is validated, HOME SLEEP AWAY displays. Manually
select HOME, SLEEP, AWAY or after a short time-out, all areas automatically arm in the
AWAY mode.
PERIM ALL
The system arms or disarms the areas and
activates the door strike relay on the 7073 or 7073A keypad.
Figure 10: All Perimeter Arming and Disarming
