DMP Electronics Thinline Aqualite 7000 Series User Manual

7000 Series Installation and Programming Guide | Digital Monitoring Products, Inc. 11
3
WIRE FOR ACCESS CONTROL
Internal Access Control Reader
The 7063/A, 7073/A, 7163, and 7173 keypads provide a built-in proximity card reader
that is compatible with most standard 125kHz proximity credentials. An external
13.56MHz proximity reader can be connected and will be compatible with 13.56MHz
proximity credentials. For a list of publicly supported card formats, see Public Card
Formats.
Note: Some proximity credentials are not compatible with DMP proximity
keypads. Test the intended proximity credentials with the application before
installation. DMP does not guarantee compatibility with credentials not
purchased from DMP.
External Access Control Reader
To accept Wiegand data input from other external card readers, connect a 12VDC
external reader to a 7073/A or 7173 keypad. Connect the red and black power wires
from the reader to the power wires from the panel. These connect in parallel with the
keypad power wires. Connect the reader (Data 1) wire to the white wire on the 5–wire
keypad cable. Connect the reader (Data 0) wire to the green/white wire on the 5–wire
keypad cable. See Figure 6.
