DMP XTL - Table of Contents

XTL/XTLC Installation Guide Digital Monitoring Products
i
Table of ConTenTs
Panel Specications
1.1 Power Supply ........................................................1
1.2 Communication .....................................................1
1.3 Keypads ................................................................1
1.4 Number of Zones ...................................................1
1.5 EnclosureSpecications .........................................1
Introduction
2.1 SystemCongurations ...........................................1
2.2 Caution Notes .......................................................1
2.3 Compliance Instructions .........................................1
System Components
3.1 Accessory Devices .................................................2
Installation
4.1 MountingLocationInformation ...............................3
4.2 MountingtheEnclosure .........................................3
Primary Power Supply
5.1 DC Input ...............................................................3
Secondary Power Supply
6.1 Standby Battery ....................................................4
6.2 Replacement .........................................................4
6.3 Battery Supervision ...............................................4
LED Operation
7.1 BacklitLogo ..........................................................5
Reset Button
8.1 Description ...........................................................5
Programming Connection
9.1 ProgrammingConnection .......................................5
On-Board 1100 Series Wireless
10.1 Wireless Antenna ..................................................5
10.2 WirelessLEDOperation..........................................5
Wireless Keypads
11.1 MountingKeypads .................................................6
11.2 Wireless Keypad Association ...................................6
Wireless Zones
12.1 Description ...........................................................6
Wireless Key Fobs and Outputs
13.1 Description ...........................................................6
Flash Load Button
14.1 Description ..........................................................6
Listed Compliance Specications
15.1 Introduction ..........................................................7
15.2 UseMarking ..........................................................7
15.3 NFPA 72 ...............................................................7
15.4 TypesOfService ...................................................7
15.5 Bypass Reports .....................................................7
15.6 Battery Standby ....................................................7
