Receiving
If the radio is turned on, it is automatically set into receiving mode.
To communicate with other radios all radios must have the
same channel and sub-channel.
Volume control
The volume can be adjusted in 7 steps.
To change the volume proceed as follows:
Press the Up-/Down button to change the volume.
The display shows the current volume level.
Monitor function
With the monitor function you can switch off the automatic squelch to
listen to the weakest signals, which are cut from the automatic squelch.
To activate the monitor press Menu button and the Down button at the
same time. A noise of weak signals is heard. To switch off the monitor
function press Menu button.
Channel selection
The WT200 offers 8 channels in the PMR band.
To change the channel proceed as follows:
Press the Menu button once, the Cannel no. fl ashes on the display.
Use the Up-/Down button to select the channel.
Press the PTT button to confi rm or wait 3 seconds, the changes are
be stored automatically.
CTCSS code
The WT200 has altogether 38 sub-channels which work in the CTCSS
standard. A private sub-audible tone may be programmed and associated
with every channel, to protect the radio from unwanted calls or interfer-
ence from other operators on the same channel. Squelch will open and
General operation
