CONNECTION DIAGRAMS
Amplifier In-Line Setup
Optional
Use only unbalanced instrument cables for audio connections.
OUT (RING/RETURN)
TRS to Y Cable
TRS Cable
TRS Cable
IN (TIP/SEND)
Feedback Path Eects
Amp
HARMAN
Power Supply
(Sold Separately)
OUT
OUT
OUT/IN
IN
IN
Amplifier Effects Loop Setup
Amp
Use only unbalanced instrument cables for audio connections.
FX Send
FX Return
HARMAN
Power Supply
(Sold Separately)
OUT
IN
OUT
IN
IN
OUT
NOTE: If the amp effects loop has a mix control, set the mix to 100% full wet.
