FUSES
WARNING!
• When replacing a blown fuse, always use an appropriate replacement fuse with the
same amp rating as the original fuse. Never replace a fuse with another fuse of
higher amp rating. Never replace a blown fuse with metal wires or any other
material. Failure to use proper fuses may result in serious personal injury, fire and/or
property damage.
• Before replacing a fuse, make sure that the ignition is off and that all the other
services are switched off and/or disengaged.
• If the replaced fuse blows again, contact an authorized dealer.
• If a general protection fuse for safety systems (air bag system, braking system),
power unit systems (engine system, gearbox system) or steering system blows,
contact an authorized dealer.
Interior Fuses
The interior fuses are located on the drivers side under the instrument panel.
Cavity Cartridge Fuse Mini Fuse Description
F1 – 20 Amp Yellow Front Heated Seats – If Equipped
F2 – 20 Amp Yellow
Rear Heated Seats, Heated
Steering Wheel – If Equipped
F3 – 10 Amp Red
Park Assist Module, Rear Camera,
Left and Right Blind Spot Sensor ,
Compass – If Equipped
F4 – 15 Amp Blue Instrument Cluster
F5 – 10 Amp Red
HV AC, Humidity Sensor,
In-V ehicle Temperature Sensor,
Inside Mirror Assembly
F18 – 15 Amp Blue Radio
F20 – 10 Amp Red
Steering Column Control Module,
Switch Bank
F21 – 10 Amp Red Diagnostic Port
F22 – 10 Amp Red
Universal Garage Door Opener,
EOM
F23 – 20 Amp Y ellow Sunroof
F24 – 5 Amp Tan Run/Accessory Relay
F25 – 5 Amp Tan Transmission Control Module #4
F26 – 5 Amp Tan Stop Lamp Switch
F27 – 10 Amp Red Pneumatic Lumbar Support
MAINTAINING YOUR VEHICLE
151
