Underhood Fuses
The Power Distribution Center is located on the right side of the engine compartment,
behind the battery. This center contains maxi fuses, mini fuses, relays, and circuit
breakers. The cavity number of each fuse is stamped on the inside cover that corresponds
to the following chart.
Cavity Maxi Fuse Mini Fuse Description
F01 70 Amp Tan – Body Control Module #1
F02 60 Amp Blue – Body Control Module #2
F03 30 Amp Green – Output For Starter Relay #1
F04 40 Amp Orange – ESC Pump Motor
F05 40 Amp Orange – Transmission Control Module #1
F06 30 Amp Green – Body Control Module #3
F07 40 Amp Orange –
EBL RLY Coil, Blower Motor RLY Coil
F09 – 5 Amp Tan Radiator Fan
F10 – 10 Amp Red ORC
F11 – 20 Amp Yellow Run/Start, Engine Control Module
F14 – 15 Amp Blue Transmission Control Module #2
F15 – 15 Amp Blue Transmission Control Module #3
F16 – 15 Amp Blue Engine Control Module,
Ignition Coils
F17 – 15 Amp Blue Brake System Module
F18 – 20 Amp Yellow Engine Control Module
F19 – 10 Amp Red A/C Compressor Clutch
F20 – 30 Amp Green Rear Defroster (EBL)
F21 – 20 Amp Yellow Fuel Pump
F22 – 10 Amp Red Occupant Restraint Controller
F23 – 25 Amp Clear Brake System Module
F24 – 20 Amp Yellow Engine Control Module,
Fuel Injectors
F30 – 20 Amp Yellow Power Outlet (Console)
F81 60 Amp Blue – Interior PDC Battery Feed,
Power Seats
F82 30 Amp Green – Amplifier
F83 40 Amp Orange – HVAC Blower Motor
F84 – 20 Amp Yellow Cigar Lighter
F85 – 10 Amp Red Sunroof, LRSM, Power Outlet
(Console), UCI/AUX Port, Cigar
Lighter
F86 – 20 Amp Yellow –
F87 – 10 Amp Red W astegate, Purge Solenoid, OBD
V ent V alve, Oxygen Sensor Heaters
F88 – 10 Amp Red Heated Outside Mirrors
MAINTAINING YOUR VEHICLE
152
