Body Control Module (BCM) Fuses
Cavity Cartridge Fuse Mini Fuse Description
F12 – – Spare
F13 – 15 Amp Blue Left Headlamp
F31 – – Spare
F32 – 10 Amp Red
Interior Lighting/Decklid/Liftgate
Release
F33 – 25 Amp Clear W indow Motor – Driver
F34 – 25 Amp Clear W indow Motor – Passenger
F36 – 15 Amp Blue Intrusion Module
F37 – 10 Amp Red Instrument Panel Cluster
F38 – 20 Amp Y ellow Door Locks
F42 – – Spare
F43 – 20 Amp Y ellow Windshield Washer Pump
F47 – 5 Amp Tan
Transmission Control Module (Tcm)
F48 – 20 Amp Y ellow Spare
F49 – 7.5 Amp Brown Stop Lamp Switch
F50 – 7.5 Amp Brown Pneumatic Lumbar Support
F51 – 7.5 Amp Brown
Cd/Hands-Free Module –
Bluetooth/Radio Display
F53 – 7.5 Amp Brown
Driver Window Switch/Power Mirrors
F89 – 5 Amp Tan Trunk Lamp
F90 – 7.5 Amp Brown Front Fog Lamps – Right
F91 – 7.5 Amp Brown Front Fog Lamps – Left
F92 – 7.5 Amp Brown High Beams (Shutters)
F93 – 15 Amp Blue Right Headlamp
MAINTAINING YOUR VEHICLE
153
To Next Page
