Cavity Cartridge Fuse Mini-Fuse Description
10 – 10 Amp Red Intrusion MOD (300) – If Equipped /
Under Hood Lamp – Police
11 – 20 Amp Y ellow Horns
12 – 10 Amp Red Air Conditioning Clutch
13 – – Fuse – Spare
14 – – Fuse – Spare
15 – 20 Amp Y ellow Left HID – If Equipped
16 – 20 Amp Y ellow Right HID – If Equipped
18 50 Amp Red – Radiator Fan – (Non 6.2L Super-
charged)
19 50 Amp Red – Electric Power Steering #2 – If
Equipped / Radiator Fan #2 (6.2L Su-
percharged)
20 30 Amp Pink – Wiper Motor
21 30 Amp Pink
20 Amp Blue –
Police
– Headlamp Washers – If Equipped
Police Bat Feed #2
22 40 Amp Green /
20 Amp Blue –
Police
– Engine Cooling Pump (6.2L Super-
charged) / Police Bat Feed # 3
23 20 Amp Blue – Police Bat Feed # 1
24 20 Amp Blue – Police Ignition Run/ACC Feed # 3
28 – – Fuse – Spare
29 – 15 Amp Blue Transmission Control Module
(Challenger/Charger Police) / Electronic
Shift Module (Challenger)
30 – – Fuse – Spare
31 – 25 Amp Clear Engine Module
32 – – Fuse – Spare
33 – – Fuse – Spare
34 – 25 Amp Clear Powertrain #1
35 – 20 Amp Y ellow Powertrain #2
36 – 10 Amp Red Anti-Lock Brake Module
37 – 10 Amp Red Engine Controller / Rad Fan Relays
(Charger/300) / Electric Power Steering
Module (Charger/300) / 5-Speed TCM
38 – 10 Amp Red Airbag Module
39 – 10 Amp Red EPS (Challenger) / EHPS (Police) / AC
Clutch Relay / Vacuum Pump Relay /
Rad Fan Relays (Challenger)
48 – 10 Amp Red AWD Module/Front Axle Disconnect – If
Equipped
49 – – Fuse – Spare
