Cavity Cartridge Fuse Mini-Fuse Description
50 – – Fuse – Spare
51 – 20 Amp Y ellow V acuum Pump
52 – 5 Amp Tan Adaptive Cruise – If Equipped
53 – – Fuse – Spare
Rear Power Distribution Center (Fuses)
There is also a power distribution center located in the trunk under the spare tire access
panel. This center contains fuses and relays. Fuse cavity location and descriptions are
printed on the inside of the power distribution center cover.
CAUTION!
• When installing the power distribution center cover , it is important to ensure the
cover is properly positioned and fully latched. Failure to do so may allow water to get
into the power distribution center and possibly result in an electrical system failure.
• When replacing a blown fuse, it is important to use only a fuse having the correct
amperage rating. The use of a fuse with a rating other than indicated may result in a
dangerous electrical system overload. If a properly rated fuse continues to blow , it
indicates a problem in the circuit that must be corrected.
Cavity Cartridge Fuse Mini-Fuse Description
2 60 Amp Y ellow – Front PDC Feed #1
3 – – Fuse – Spare
4 60 Amp Y ellow – Front PDC Feed #2
5
30 Amp Pink
20 Amp Blue – Police
– Sunroof/Dome Lamp – Police
6 40 Amp Green – Exterior Lighting #1
7 40 Amp Green – Exterior Lighting #2
8 30 Amp Pink – Interior Lighting
9 40 Amp Green – Power Locks
10 30 Amp Pink – Driver Door Control Module
11 30 Amp Pink – Passenger Door Control Module
12
– 20 Amp Yellow Dual USB Center Console Rear/
Cigar Lighter IP – If Equipped
15 40 Amp Green – HVAC Blower
16 20 Amp Blue – Left Spot Lamp – Police
17 – – Fuse – Spare
18 30 Amp Pink – Mod Network Interface – Police
19 – – Fuse – Spare
20 – – Fuse – Spare
21 30 Amp Pink – Fuel Pump
MAINTAINING YOUR VEHICLE
234
