Dodge CHARGER Hellcat 2017 - Page 237

Cavity Cartridge Fuse Mini-Fuse Description
22
– 20 Amp Yellow – Po-
lice
Right Spot Lamp – Police
23 – 10 Amp Red Fuel Door/Diagnostic Port
24 – 10 Amp Red Integrated Center Stack
25 – 10 Amp Red Tire Pressure Monitor
26
– 15 Amp Blue Cygnus Transmission Module
(Charger/300) / Electronic Shift
Module (Charger/300)
27 – 25 Amp Clear Amplifier – If Equipped
31 – 25 Amp Breaker Power Seats – If Equipped
32 – 15 Amp Blue HVAC Module/Cluster
33
– 15 Amp Blue Ignition Switch/RF Hub
Module/Steering Column Lock
(300) – If Equipped
34
– 10 Amp Red Steering Column Module/Clock
(300)
35 – 5 Amp Tan Battery Sensor
36
– 15 Amp Blue Electronic Exhaust Valve – If
Equipped
37 – 20 Amp Yellow Radio
38
– 20 Amp Yellow Power Outlet Inside Arm Rest/
Console Media Hub
40 – – Fuse – Spare
41 – – Fuse – Spare
42 30 Amp Pink – Rear Defrost
43
– 20 Amp Yellow Comfort Seat And Steering
Wheel Module (Heated Steer-
ing Wheel/RR Heated Seats)
44
– 10 Amp Red Park Assist / Blind Spot / Rear
View Camera
45
– 15 Amp Blue Cluster / Rearview Mirror /
Compass (Charger/300) / Hu-
midity Sensor / Forward Facing
Camera (Lane Departure)
46 – – Fuse – Spare
47
– 10 Amp Red Adaptive Front Lighting / Day
Time Running Lamps – If
Equipped
48
– 20 Amp Yellow Active Suspension – (6.4L /
6.2L)
49 – – Fuse – Spare
50 – – Fuse – Spare
MAINTAINING YOUR VEHICLE
235
