Dolmar MS-20 C

To Next Page

To Previous Page

Page

Pos.

MS-20 C

MS-22 C

Part No. Notes Description Specifications

3 1 1 374 401 700 HANDLE SET INC. 2,3

3 2 4 374 401 603 SCREW

3 3 4 381 270 500 NUT M5

3 4 1 374 502 100 CONTROL LEVER ASS'Y INC. 152-160, SECTION 6

3 5 1 381 700 500 HANGER ASS'Y INC. 6

3 6 1 381 005 936 SCREW & WASHER ASS'Y

3 7 1 367 951 470 CAUTION LABEL

3 8 1 374 100 100 SHAFT PIPE COMPLETE

3 9 1 374 952 130 CAUTION LABEL

3 10 1 374 801 400 STANDARD EQUIPMENT PROTECTOR ASSY INC. 11,14-16

3 11 1 367 806 100 STANDARD EQUIPMENT PROTECTOR ASS'Y INC. 12,13

3 12 2 381 006 979 BOLT M6X30

3 13 1 382 850 820 PROTECTOR CLAMP

3 14 2 381 005 938 SCREW ASSEMBLY

3 15 1 367 800 800 PROTECTOR COMPLETE

3 16 2 367 180 500 NUT M5

3 17 1 367 905 949 SOCKET HEAD BOLT M5X14 (W,SW)

3 18 1 367 150 630 SHAFT

3 19 1 382 300 600 CASE,GEAR ASSY INC. 20-33

3 20 1 381 142 400 INNER SNAP RING

3 21 1 374 300 612 OUTER SNAP RING

3 22 1 381 250 030 BALL BEARING #609ZZ

3 23 1 367 905 989 SOCKET HEAD BOLT M5X25

3 24 1 367 301 101 OIL BOLT M6X9

3 25 1 381 850 020 GUARD

3 26 2 381 005 939 SCREW ASSEMBLY

3 27 1 367 006 999 BALL BEARING 626ZZ

3 28 1 388 010 991 BALL BEARING 6000DDU

3 29 1 381 142 600 INNER SNAP RING

3 30 1 367 850 160 RECEIVE WASHER

3 31 1 381 800 300 CLAMP COMPL. WASHER

3 32 1 367 850 500 NUT

3 33 1 388 300 800 CUTTER SHAFT SET

MS-22 C

Dolmar MS-20 C - Page 7
