Dolmar MS-335.4 U - Mounting of Protector

11
Turn the machine upside down, and you can replace the nylon cutting head
easily.
MOUNTING OF NYLON CUTTING HEAD
– The nylon cutting head should go on top of the receiver washer (1).
– Insert the hex wrench through the hole in the gear case and rotate the
receiver washer (1) until it is locked with the hex wrench.
– Then screw the nylon cutting head onto the shaft by turning it counter-
clockwise.
– Remove the hex wrench.
Rotation
Loosen
Tighten
Hex wrench
(1)
