9
CAUTION: Before doing any work on the String Trimmer, always stop the
engine and pull the spark plug connector off the spark plug.
Always wear protective gloves!
CAUTION: Start the String Trimmer only after having assembled it completely.
For machines with bike handle models
– Loosen knob (1).
– Place handle (4) between handle clamp (2) and handle holder (3).
– Adjust handle (4) to an angle that provides a comfortable working position
and then secure by rmly hand-tightening knob (1).
CAUTION: Do not forget to mount spring (5).
MOUNTING OF HANDLE
Engine
Engine
For machines with loop handle
– Fix a barrier to the left side of the machine together with the handle for
operator protection.
– Do not adjust position of the loop handle too close to the control grip. Keep
not less than 250 mm distance between the handle and the grip.
(a distance collar is provided for this purpose.)
