Dolmar MS290.4U - PARTS DESCRIPTION

7 ENGLISH
PARTS DESCRIPTION
MS290.4U, MS290.4L
1
3
2
9
4
10
16
1
2
3
6
6
4
5
5
8
7
8
7
9
11
13
15
17
18
19
21
20
22
12
14
1 Sparkplugcover 2 Aircleanercover 3 Primer pump 4 Stop button
5 Lock-offlever 6 Hanger 7 Throttletriggeradjust-
ment dial
8 Throttle trigger
9 Handle 10 Knob 11 Barrier(countryspecic) 12 Hanger(countryspecic)
13 Protector(universal
type)
14 Protector (narrow type)
(countryspecic)
15 Protector extension 16 Chokelever
17 Fuel tank cap 18 Fuel tank 19 Starter handle 20 Mufer
21 Oil tank cap 22 Shoulder harness - - - -
NOTE:Thetypeofcuttingtoolandshoulderstrapvarydependingonthecountry.
