Dolphin DRC-1G - Specifications & Dimensions

3
1. Specifications and Dimensions
MODEL
DRC-1(Dolphin Rack Conveyor Dishwasher)
DRC-1G(L/R)
DRC-1E(L/R)
DIMENSIONS
STANDARD TYPE
STANDARD TYPE
1,400(L)×720(W)×1615(H)mm
1,400(L)×740(W)×1445(H)mm
TYPE
GAS TYPE ELECTRIC TYPE
1. MATERIALS : STS-304 1.0T, 1.2T, 1.5T 2.0T
2. ELECTRIC SPECIFICATIONS : 380V 3Ph 4 wired, 220V 1Ph
3. ELECTRIC CONSUMPTION : 5.8 KW (GAS TYPE), 36.7KW(ELECTRIC TYPE)
4. WASH PUIMP : 1.7kw(220V 1Ph & 380V 3Ph, 500 L/min)×1ea
5. WASH TANK CAPACITY : 80 Liter×1ea
6. WASH TEMPERATURE : 60℃~70℃
7. HEATING ELEMENT FOR WASH TANK : 4 KW x 1EA
8. WASH TYPE : POWERFUL WASH
9. GAS BOOSTER : INSTANT GAS BOOSTER BY LNG OR LPG
2~3 UNIT OF GAS BOOSTER(W/O TANK)
OR 1 UNIT OF GAS BOOSTER(W/ TANK)
ELECTRIC BOOSTER: 27KW ELECTRIC HEATER EQUIPPED
10. WATER CONSUMPTION : WASH TANK - 80 L×1EA
RINSE WATER CONSUMPTION – 600 L/hr
11. HEAT QUANTITY : FOR WASH TANK - 4,400 Kcal/h
FOR RINSE TANK – LNG 42,000 Kcal/h, LPG 3.5 kg/h
※DEPENDING ON KITCHEN ENVIRONMENT
12. CONVEYOR SPEED : 0-2 M/min(SPEED CONTROL MOTOR: 180W, SPEED CONTROL AVAILABLE)
13. NOZZLE TYPE : WASH NOZZLE – UPWARD & DOWNWARD ROTATING FIXED NOZZLE(REMOVABLE)
RINSE NOZZLE - UPWARD & DOWNWARD FIXED NOZZLE(REMOVABLE)
14. SAFETY DEVICE : OVERLOAD RELAY
EMERGENCY SWITCH AT INLET AND OUTLET
15. WASH CAPACITY : RACK 170-180EA/HOUR (CONVEYOR SPEED 1.5 M/min)
※DEPENDING ON USAGE ENVIRONMENT
16. OTHER SPECIFICATION : GAS – INSTANT GAS HEATER 16L(W/O TANK),15A, 2.6 Kg/h
INSTANT GAS HEATER 16l(W TANK), 15A, 3.5 Kg/h
TAP WATER CONNECTION – PRESSURE:1.2 Kg/cm
2
, PIPE : 15A OVER,
DRAINING CONNECTION - 40A OVER PIPE AT BOTTOM OF THE M/C
