Connecting the Access Manager to two passive readers (HiSec)
The following device illustrations are schematic diagrams. Details of the
devices can deviate from these.
Malfunctions due to the use of excessively long cables.
Use a cable with a maximum length of 500 m (RS 485)
between the control unit and the last Passive reader.
Functional problems by actuating the DIP switches with
voltage applied.
Only actuate the DIP switches on the device in a dead-
voltage state.
Make sure that DIP switches (1) 1 and 2 on the control unit and the passive
reader are in the ON position.
