To separate the transparent cover
from the front module, proceed as
follows:
Use a screwdriver to release the
first locking hook.
Pull the transparent cover around
10 mm out to the front.
Turn the front module by 180°.
Use a screwdriver to release the
second locking hook.
Pull the transparent cover
completely off the front.
Position the cover frame with inserted standard intermediate frame on the
back module and hold this tight.
