Sample lockings without masterkey wafers
core
N AB N N N AB
0 4 1 2 2 6
FB N FB N N N
P1 P2 P3 P4 P5 P6
body
There is no restriction of the positions for core
pins. Therefore, an AB pin is applied at position
P6 depending on length.
Sample lockings with masterkey wafers
core
N AB AB AB AB N
3 4 7 5 6 3
5
FB FB N N N N
P1 P2 P3 P4 P5 P6
body
If two values of the body pins are equal (here:
length 5 on pos. P1 and P4), the FB body pin
must be inserted at the first possible position.
(here at pos. P1)
