Assembly without masterkey wafers
Note! Only N pins are available as core pins for the lengths of 0, 1, 2, 3,
and for the lengths 4, 5, 6, 7 only AB pins are available.
Core pins
AB AB N N N AB
4 5 1 2 3 5
P1 P2 P3 P4 P5 P6
The core pins are applied at positions P1 – P6
depending on their lengths.
here: Position P1, P2 and P6: AB-pin;
Position P3, P4 and P5: N-pin
Assembly with masterkey wafers
Core pins
AB AB N N N AB
4 5 1 2 3 5
3 4 5
6 7
P1 P2 P3 P4 P5 P6
For assembly superstructures with masterkey
wafers the values of core pins are shown in the
upper cells. Assignment of pins is done similar
to assembly superstructures without masterkey
wafers. (see above)
