3
1. To replace an older toilet, turn off water supply to toilet. Disconnect water line
at toilet water valve. Unscrew oor bolt nuts and remove toilet. Discard old
oor seal and mounting bolts. The old oor ange may be used if it is in good
condition and has fastener holes that are positioned correctly. Make sure center
of oor ange is at least 11 inches (279 mm) from back wall (Figure A).
2. When installing new oor ange, make certain that the toilet mounting bolts align
properly with Dometic toilet mounting pattern.
3. Secure ange to oor using at head screws through countersunk holes in ange.
Insert oor bolts into slotted holes in ange (Figure B).
4. If toilet is being installed in a shower stall, apply a 1/4" thick by 3/4" wide bead of
glazing compound around the circumference of the oor ange (Figure C).
5. Dometic toilet models 111, 510 and 511 will accept handicap or household decora-
tive seats. Remove existing seat and replace with new seat if desired.
6. Position oor seal by pressing the oor bolts up through holes in the seal.
7. Set toilet in place with bolts protruding up through mounting holes in base
(Figure D).
8. Install washers and hex nuts provided with toilet. Tighten nuts down equally with
standard 7/16" open end wrench. Remove excess glazing compound from around
base in shower stall installation.
9. Connect water supply line to water valve (1/2" NPT) inlet using appropriate ttings
or an extension (Figure E).
10. Turn on water supply and ush toilet to test for leaks.
11. Attach pedestal and pedal covers to toilet base (see instructions below).
Fig. B
Fig. D
Fig. E
Fig. A
2. Tall model – screw
cover together.
Short model –
snap together.
1. Wrap pedestal cover
around base so that
it closes as shown.
3. Slide pedal cover
onto foot pedal rod.
4. Secure side plate
onto pedal cover
with screws.
Fig. C
