Dometic8700 Installing the awning
7
6 Installing the awning
6.1 Notes on the installation
!
WARNING! Failure to obey these warnings could result in death
or serious injury.
Fire hazard/Electrocution hazard
• Make sure there are no obstacles (wires, pipes, etc.) on the RV‘s roof
and inside the RV‘s walls.
•Shut off gas supply to the RV.
• Disconnect AC power from the RV, and disconnect the positive
+12 Vg terminal from the supply battery(s) before drilling or cutting
into the RV.
Impact or crush hazard
• The device may become unstable and could detach, bend, or col-
lapse. Make sure mounting surface on the RV is flat, has solid structural
backing where fasteners penetrate the surface, and will safely and
securely support the product.
• Find a solid structure in the RV wall for support of top mounting
brackets.
Hardware
(fig. 3)
878HT-WH
878HT-BK
(Tall – Black or
White)
878HS-WH
878HS-BK
(Standard – Black
or White)
878HU-WH
(Ultra short White)
Height range 1892 mm – 2235 mm 1626 mm – 1930 mm
1
499 mm – 1676 mm
Main arm (1) length 1854 mm 1549 mm 1385 mm
Adjustable arm (2)
length
1448 mm 1448 mm 1288 mm
Main rafter (3)
length
1676 mm 1372 mm 1244 mm
Secondary rafter (4)
length
826 mm 1130 mm 1130 mm
