Technical data ACX3
28
11 Technical data
ACX3 30 ACX3 40
Gas consumption: 12.6 g/h
Nominal heat input
Butane: 175 W
Minimum heat input
Butane: 128 W
Connection voltage: 12 Vg
220 – 240 Vw, 50/60 Hz
Power consumption: 75 W 85 W
Cooling capacity: max. 30 °C below ambient temperature
Total volume: 33 l 41 l
Energy consumption: 1.4 kWh/24 h 1.6 kWh/24 h
Climate class: N
Ambient temperature: 16 to 32 °C
Noise emission: >0 dB
Refrigerant: 159 g H
2
O+86g NH
3
Dimensions
(W x H x D) in mm: see fig. c, page 11 see fig. d, page 11
Weight: Approx. 15 kg Approx. 16 kg
Inspection/certification:
2806
ACX3 30 ACX3 40
28 – 30 mbar, 30 mbar,
37 mbar
28 – 30 mbar, 30 mbar,
37 mbar
Ref. no.: 9600028404, 9600028405,
9600028406, 9600028413
9600028408, 9600028409,
9600028410, 9600028411
ACX3 30 ACX3 40
50 mbar 50 mbar
Ref. no.: 9600028403 9600028407
