6.1 Control panel
You can regulate the system using the control panel.
The following control and display elements are available for operating the
system:
No. in
fig. 1,
page 2
Explanation
1
ON/OFF button
2
Fault LED (red):
The LED indicates system malfunctions.
3
Compressor LED (yellow):
The LED lights up when the compressor is operating.
4
Mode button:
You can use the Mode button to switch between operating
modes 1, 2 and Automatic.
5
Digital display:
This displays:
– The selected operating mode
for operating mode 1
for operating mode 2
A for automatic mode
– selected room temperature in °C
6
+ button:
The + increases the temperature by 1 °C.
7
– button:
Die Taste - decreases the temperature by 1 °C.
8
Power LED (green):
The LED indicates that the system is switched on.
