A.Roof Vent Locations (FIG. 4.A)
1.
Remove all screws that secure the vent to the roof
and remove the vent from the opening.
There may be electrical wiring located
be-
2.
Remove all sealing compound from around the
vent opening.
tween roof and ceiling. Disconnect all elec-
3. Seal all screw holes and all roof seams with a
tricky. (FIG. 4)
quality all weather sealant.
4
1)
REMO\E
SCREWS
f Seam)
3) SCRAPE PUTTY
B.
1.
2.
SEAL HOLES
&
SEAMS
3.
Carefully
cut
a matching hole through
the
ceiling
of
the van. (FIG.
4.B.3)
FIG. 4.B.3
AIR BOX PERIMETER
\
355 x 355 mm
Other:
Cutting new or modifying existing openings.
This opening should be located between roof
struc-
4.
Seal holes and seams. (FIG. 4.A)
tural members.
Mark the 355 x 355 mm opening on the roof with a
marker. (FIG.
4.B.1)
Carefully cut the opening in the roof.
(FIG.
4.B.2)
FIG. 4.B.2
CUT HOLE
DEPENDS ON
STRUCTURE
DON’T REMOVE
STRUCTURE
GOOD
LINES
